GB4270 China Heavy Duty High Quality Metal Band Saw Machines
No content added
Introduction
Product feature of GB4270 China Heavy Duty High Quality Metal Band Saw Machines
1. Hydraulic control of cutting speed, stepless adjustment 2. The structure of the guide block is scientific and reasonable, which prolongs the service life of the saw blade 3. Double column structure, stable operation 4. Stable sawing and high precision 5. The work clamping adopts hydraulic clamping, which is easy to operate. 6. Customizable three-way hydraulic clamping device
| Specifications | GB4260 | GB4270 | GB4280 |
| Max.cutting(mm) | 600 600W×600H | 700 700W×700H | 800 800W×800H |
| Saw blade speed(m/min) | 20-80(frequency control) | 20-80(frequency control) | 20-80(frequency control) |
| Saw blade size(mm) | 6640×54×1.6 | 7150×54×1.6 | 8820×67×1.6 |
| Main motor(kw) | 5.5 | 7.5 | 7.5 |
| Working clamping mode | Hydraulic vise | Hydraulic vise | Hydraulic vise |
| Main transmission structure | Worm gear transmission | Worm gear transmission | Worm gear transmission |
| band saw blade tensioning method | Manual | Manual | Manual |
| Cleaning | wire brush & flood coolant | wire brush & flood coolant | wire brush & flood coolant |
| Hydraulic motor(kw) | 1.5 | 1.5 | 1.5 |
| Cooling motor power(kw) | 0.125 | 0.125 | 0.125 |
| Dimensions(mm) | 3130×1600×2300 | 3700×1700×2300 | 4130×2200×2600 |
| Machine size(mm) | 2380×1350×1950 | 2500×1550×2200 | |
| Machine Weight(kg) | 1400 | 1600 | |
